| Suitable for pipes: PEX-AL-PEX, PE-RT/AL/PE-RT |
| Pipe dimensions: 16 x 2.0 mm |
| Connection type: press-fit |
| Pressing profile: TH or U |
| Body material: brass |
| Press ring material: stainless steel AISI 304 |
| Max. working pressure: 10 bar |
| Max. working temperature: 95 °C |
| Application: heating, cooling, and water supply systems |
| Parameters: |
| Outer diameter: 16 mm |
| Wall thickness: 2.0 mm |
| Inner diameter: 12.00 mm |
| Structure: PEX / adhesive / AL / adhesive / PEX |
| Maximum operating temperature: +95 °C |
| Short-term temperature: up to +110 °C |
| Maximum operating pressure: 10 bar (at +20 °C) / 6 bar (at +95 °C) |
| Oxygen diffusion barrier: yes, complies with DIN 4726 |
| Suitable connections: press-fit, threaded, eurocone |
| Installation radius (without tools): ≥ 130 mm |
| Color: white |
